LAND ROVER ACCESSORY FITTING INSTRUCTIONS

VEHICLE :
PART NO :
KEYWORD :

LAND ROVER

DEFENDER

SEAT COVERS

VPLES0560 / VPLES0620 / VPLES0561 / VPLES0562 / VPLES0563 / VPLES0564

FITTING INSTRUCTION

WARNING
  • Accessories which are not correctly installed can be dangerous. Read the instructions carefully prior to installation. Comply with instructions at all times. If in doubt, contact your nearest approved retailer.
CAUTION
  • Make sure isofix anchor points are accessible after seat cover installation.
Accessory Part Number
Seat covers row 1 - 'Defender 90 and 110' VPLES0560
Seat covers row 1 - 'Defender Commercial' only VPLES0620
Seat covers row 2 - (5 seats) 'Defender 110, and 130' only VPLES0562
Seat covers row 2 - (7 seats) 'Defender 110, and 130' only VPLES0563
Seat covers row 3 - 'Defender 110' only VPLES0564

Seat covers row 1 (Bill of Materials) - VPLES0560 / VPLES0620

Seat covers row 2 (Bill of Materials) - VPLES0561 / VPLES0563

Seat covers row 2 (Bill of Materials) - VPLES0562

Seat covers row 3 (Bill of Materials) - VPLES0564

NOTE
  • Isofix capability for front passenger seat.
Fitting Instruction
NOTE
  • The following instructions are for both sides of the vehicle.
  • This procedure contains some variation in the illustrations depending on the vehicle specification, but the essential information is always correct.
1

Row 1 seat covers installation step 1.

  1. Install front seat cover (A) over headrest. Make sure the seat cover label is on the outside of the front seat (closest to the vehicle door).
2

Row 1 seat covers installation step 2.

  1. Make sure the retainers are fully inserted between the seat cushion and the seat back.
3
WARNING
  • Make sure all the seatbelt buckles and isofix anchor points are accessible.

Row 1 seat covers installation step 3.

  1. Make sure the side tabs are fully inserted between the seat cushion and the plastic trim.
  2. Make sure the front elasticated hem is correctly positioned to make sure the cover is not loose.
4

Row 1 seat covers installation step 4.

  1. Install the head restraint cover (B) for larger head restraints. Install the head restraint cover (C) for smaller head restraints.
5
NOTE
  • Cover VPLES0563 only.

Row 2 seat covers installation step 1.

  1. Partially lower the centre seat back and lower the armrest.
6
NOTE
  • Cover VPLES0563 only.

Row 2 seat covers installation step 2.

  1. Lower the cover (D) over the central seat back. When the cover is halfway down the seat, slide the arm rest into the arm rest cover section of the cover.
7
CAUTION
  • Make sure the cover hole fits over the seat latch as shown.
NOTE
  • Cover VPLES0563 only.

Row 2 seat covers installation step 3.

  1. Slide the central seat cover section over the seat back. Slide the integrated armrest cover over the armrest pulling the armrest strap through the hole in the cover.
8
NOTE
  • Cover VPLES0563 only.

Row 2 seat covers installation step 4.

  1. Partially lower the seat back.
9
NOTE
  • Cover VPLES0563 only.

Row 2 seat covers installation step 5.

  1. Slide the cover (E) over the seat back. Go to step 14.
10
NOTE
  • Cover VPLES0562 only.

Row 2 seat covers installation step 1.

  1. Partially lower the seat back (LH side), centre seat back and lower the armrest
11
NOTE
  • Cover VPLES0562 only.

Row 2 seat covers installation step 2.

  1. Slide the cover (M) over the seat back.
12
CAUTION
  • Make sure the cover hole fits over the cup holders as shown.
NOTE
  • Cover VPLES0562 only.

Row 2 seat covers installation step 3.

  1. When the cover is halfway down the seat back, slide the arm rest into the arm rest cover section of the cover.
13
NOTE
  • Cover VPLES0562 only.

Row 2 seat covers installation step 4.

  1. Slide the central seat cover section (N) over the headrest and seat back. Make sure the latches are accessible through the cover holes.
14

Tuck the tabs under the head restraints

15

Velcro the tabs to the rear of the seat cover.

16
WARNING
  • Make sure all the seatbelt buckles and isofix anchor points are accessible.
NOTE
  • Cover VPLES0563 only.

Install the lower section of the seat cover over the seat isofix flap.

17
NOTE
  • Cover VPLES0563 only.

Zip up the side seat cover zip.

18
WARNING
  • Make sure all the seatbelt buckles and isofix anchor points are accessible.
NOTE
  • Make sure the side retainers are fully inserted between the seat cushion and the plastic trim.
  • Make sure the front elasticated hem is correctly positioned to make sure the cover is not loose.

Install the lower part of seat cover over the seat cushion.

19

Partially lower the seat back.

20
NOTE
  • Cover VPLES0563 only.

Slide the cover (F) over the seat back.

21

Tuck the tabs under the head restraints and velcro to the rear of the seat cover.

22
WARNING
  • Make sure all the seatbelt buckles and isofix anchor points are accessible.
NOTE
  • Make sure the retainers are fully inserted between the seat cushion and seat back.
  • Make sure the side tabs are fully inserted between the seat cushion and the plastic trim.
  • Make sure the front elasticated hem is correctly positioned to make sure the cover is not loose.
  • Cover VPLES0563 only.

Install seat cushion cover (G).

23
NOTE
  • Cover VPLES0562 only.

Slide the cover (L) over the seat back.

24
WARNING
  • Make sure all the seatbelt buckles and isofix anchor points are accessible.
NOTE
  • Make sure the retainers are fully inserted between the seat cushion and seat back.
  • Make sure the side tabs are fully inserted between the seat cushion and the plastic trim.
  • Make sure the front elasticated hem is correctly positioned to make sure the cover is not loose.
  • Cover VPLES0562 only.

Install seat cushion cover (L).

25

Install the 3 head restraint covers. The smaller cover (J) should fit over the centre head restraint

26

Row 3 seat covers installation step 1.

  1. Raise the third row seats and head restraints.
27
WARNING
  • Make sure the seat cover label and elasticated strap are on the outside of the seat (closest to the vehicle side).
NOTE
  • Pull the rear seat strap through the seat cover hole.

Row 3 seat covers installation step 2.

  1. Slide the third row cover over the seat. Before fully pulling down, insert the head restraint into the integrated headrest cover.
28
WARNING
  • Make sure all the seatbelt buckles and isofix anchor points are accessible.
NOTE
  • Make sure the side tabs are fully inserted between the seat cushion and the plastic trim.
  • Make sure the front elasticated hem is correctly positioned to make sure the cover is not loose.

Row 3 seat covers installation step 3.

  1. Install the seat cushion part of the cover and secure the head restraint cover with the 3 locators, two on the front and one on the rear.
29
NOTE
  • Installing the strap from the rear of the seat may aid ease of installation.

Row 3 seat covers installation step 4.

  1. Hook the elasticated strap and tab over the inside of the seat frame as shown. Detail image shown from rear of seat.
